single post digital metal detector XLD-H with high High Sensitivity
Technical specifications: |
Electric current | 110~220V | Power | <30w |
Outer frame | 2200mm(h)X800mm(w)X500mm(d) | Inner frame | 2010mm(h)X700mm(w)X500mm(d) |
Weight | about 80kg | work envionment | -20°C- +45°C |
Complied standards: | GB15210-94 | | |
Six detecting area : Allocation of six mutual over-lapping detecting areas, accurately
ascertain the location of the metal articles
Convenient operation: operation panel is made of film .This high light panel can show
the alarm area directly, display the metal articles direction,size
accurately,and have sound & light alarm simutateously.This clear
function improves work efficiency greatly.We are able to add
controller equipment according to the customer’s request.
Adjustable area sensitive: The maximum sensitivity can detect a
paperclip .Each detecting area has 100 sensitive gears ,and can adjust
sensitivity automatically, Predetermine the weight ,volume ,size
and location of the metal article , Eliminate the false alarm
caused by coins ,keys ,jewelleries and leather bell buttons,etc.
Digital circuit:design prevents from missing alarm , and have strong
anti-interferendce to outer surroundings ,the rate of the false
alarm is controlled within 1%
Statistic function:
Intellectual rate of flow of passer and alarm counter can calculate
the number Of passer and alarm times
Application scope:It can be used in the factory,prison,court,exhibition
hall,stadium,entertainment places
As for walkthrough metal dectors, we have many types, XLD-B(LDC),
XLD-B(LED), XLD-A1 Waterproof, XLD-D, XLD-E(LCD) and XLD-II series,
and welcome to ask our newest prices.
